Product Description
RFID laundry tags are specially designed to meet the tracking requirements of the laundry industry and uniform management in hotel or hospital etc. It is easily affixed onto textile products using a standard sewing process, it can be sewed along the edge of the item or embedded into the Item, and can bear washing, dry clean, high Temperature sterilization
| Protocol |
EPC CLASS1 Gen 2 / ISO 18000-6C |
| Chip |
NXP Ucode 7m chip |
| Work Frequency |
840—960MHZ |
| Memory capacity |
EPC 128bit, User 32bits, password 32 bits, TID 96 bits |
| Work mode |
Read/Write |
| Storage time |
>10years |
| Erasable times |
>100,000times |
| Life cycle |
>200 times( one year) |
| Material |
Soft textile |
| Tag polarization |
Linear polarization |
| Read range |
>2meters(depend on reader and working environment) |
| Color |
White( customized optional) |
| N.W. |
1.1g/pc |
| Unit Dimension |
70*15*1.45mm (customized size optional) |
| Package dimension |
430*210*270mm( 4200pcs/package) |
| Working Tem. |
-25℃~+70℃ |
| Ironing Tem.(press 4bar) |
85℃with 60 minutes, 120℃ with 10minutes, 150℃ with 4 minutes, 180℃ with 10 seconds |
| Humidity |
8-100% RH |
| Certificate |
ROHS |
| Laser encoding |
Support |
